005 is a 1981 arcade game by SEGA, in which the player's mission is to take a briefcase of secret documents to a waiting helicopter. It is one of the first examples of a stealth video game.

Arcade cabinet[]

The game came in a fairly generic wood-grain panel cabinet. The sticker side art was optional, which made it easy to change the games around when necessary. The game boards were SEGA G80-compatible, and will work in any such cabinet. As with most early SEGA titles, the monitor is vertically mounted. The bezel around the monitor sported the standard instructions; the marquee showed a "005" logo and a flashlight.

Official world record[]

Gamer Dwayne Richard holds the official world record for this game with a maximum possible 1,500,000 points.[citation needed]

Arcade Specifications[]

Arcade Specifications
Physical Specifications
Cabinet Upright, Cocktail
Dimensions Upright: 71.25" high x 26" deep x 25" wide
Cocktail: 25.25" high x 35.5" deep x 27.5" wide
Orientation Vertical
Weight Upright: 330 lbs.
Cocktail: 170 lbs.
Technical Specifications
System/Board SEGA G80
CPU Z80 (@ 3.86712 MHz)
Sound Chipset Samples (@ 3.86712 MHz)
Colors 65
Display Raster
Resolution 224 × 256
